 标准网带宽度
| inch |
3.0 |
6.0 |
9.0 |
12.0 |
15.0 |
18.0 |
21.0 |
24.0 |
27.30 |
30.0 |
| mm |
76 |
152 |
228 |
305 |
381 |
457 |
533 |
607 |
683 |
838 |
| inch |
33.0 |
36.0 |
39.0 |
42.0 |
45.0 |
48.0 |
51.0 |
54.0 |
57.0 |
60.0 |
| mm |
762 |
914 |
990 |
1066.8 |
1143 |
1295.4 |
1295.4 |
1371.6 |
1447.8 |
1524 |
| inch |
63 |
66 |
69 |
72 |
75 |
78 |
81 |
84 |
87 |
93 |
| mm |
1600.2 |
1676.4 |
1752.6 |
1828.8 |
1905 |
1981.2 |
2057.4 |
2133.6 |
2209.8 |
2362.2 |
| inch |
90 |
96 |
99 |
102 |
105 |
111 |
111 |
114 |
117 |
120 |
| mm |
2286 |
2438.4 |
2514.6 |
2590.8 |
2667 |
2819.4 |
2819.4 |
2895.6 |
2971.8 |
3048 | |
 |
 |
网带链链轮规格
|
齿数 |
轴心内径 |
节圆直径 |
齿轮直径 |
毂直径 |
毂宽 |
齿宽 |
|
最小 |
最大 |
| mm inch |
mm inch |
mm inch |
mm inch |
mm inch |
mm inch |
mm inch |
| 10 |
10.00 0.39 |
18 0.71 |
41.1 1.62 |
40.1 1.58 |
28.0 1.10 |
28.0 1.10 |
2.0 0.08 |
| 19 |
19.05 0.75 |
40.0
1.57 |
77.2
3.04 |
76.2
3.00 |
64.0 2.52 |
64.0 2.52 |
2.0 0.08 |
| 28 |
19.05 0.75 |
60.0 2.36 |
113.4 4.46 |
112.4 4.43 |
75.0 2.95 |
75.0 2.95 |
2.0 0.08 |
| 38 |
19.05 0.75 |
60.0
2.36 |
153.8
6.06 |
152.8 6.02 |
75.0 2.95 |
75.0 2.95 |
2.0
0.08 | | |
|
|
 |
|
板宽(A) |
自重 |
| mm inch |
kg/m |
| 76.2 3 |
1.0 |
| 152.4 6 |
1.9 | |
|
|
 |
网带链链轮
|
齿数 |
外径 |
节圆径 |
轴径 |
| 16 |
130.60 |
130.20 |
25，30，35 |
| 18 |
146.90 |
146.28 |
25，30，35 |
| 21 |
170.70 |
170.43 |
25，30，35 | | |
|
|
 |
